Apraksts

• Manufacturer E-SWITCH
• Type of switch microswitch TACT
• Contacts configuration SPST
• Contacts configuration
• Number of positions 2
• Stable positions number 1
• DC contacts rating @R(at resistive load) 50mA / 12V DC
• at resistive load
• Mounting THT
• Illumination none
• Operating Force 1,57N
• Body dimensions 6,2x6,2x3,6mm
• Button height(measured from PCB) 9,5mm
• measured from PCB
• Switching method(the position in bracket indicates momentary position.) OFF-(ON)
• The position in bracket indicates momentary position.
• Terminal pitch 5mm
• Button shape round
• Actuator colour black
• Key stroke 0,25mm
• Leads round pin
• Max. contact resistance: 100mΩ
• Mechanical durability 80000 cykli
• Masa bruto0.334 g

Parametri

THT
SPST-NO
0.05A/12VDC
6x6x4mm
6mm
Horizontāli
1.57N
