Apraksts

• Manufacturer LITTELFUSE
• Type of fuse fuse
• Current rating 0,63A
• Rated voltage 250V AC
• Fuse characteristics quick blow
• Kind of fuse miniature
• Fuse size TR5
• Mounting THT
• Manufacturer series 370
• Breaking capacity 35A
• Breaking characteristics 1,5In: min 1h, 2,75In: min 10ms, 2,75In: max 3s, 4In: min 3ms, 4In: max 300ms, 10In: max 20ms
• Max voltage drop 115mV
• Contact material copper
• Terminal pitch 5,08mm
• Energy I2t 0,076A2s
• Fuses application standard applications
• Soldering temperature 260°C / 3 s
• Power dissipation 0,2W
• Pin diameter 0,6mm
• Kind of package bulk
• Contact plating tinned
• Operating temperature -40...85°C
• Leads for soldering
• Masa bruto0.44 g

Parametri

0.63A
250VAC
Ātrs
