Apraksts

• Manufacturer BREVE TUFVASSONS
• Type of transformer encapsulated
• Power 16VA
• Primary voltage 230V AC
• Secondary voltage 1 12V
• Secondary voltage 2 12V
• Secondary winding current 1 666.6mA
• Secondary winding current 2 666.6mA
• Mounting PCB
• IP rating IP00
• Conform to the norm PN-EN 61558-1:2000,  PN-EN 61558-2-1:2000,  PN-EN 61558-2-6:2000
• Thermal class Ta40B
• Secondary winding terminals 8-9, 13-14
• Primary winding terminals 01.июл
• Weight 420g
• A dimension 47mm
• A1 dimension 30mm
• A2 dimension 30mm
• B dimension 57mm
• C dimension 39mm
• Electrical insulation strength 4kV/60s
• Additional information
• Gross weight: 415.8 g
• Manufacturer part number: TEZ16/D230/12-12V

Parametri

2x12VAC
2
2x530mA
16VA

Papildu dokumentācija
