Apraksts

• Manufacturer BREVE TUFVASSONS
• Type of transformer encapsulated
• Power 1.5VA
• Primary voltage 230V AC
• Secondary voltage 1 15V
• Secondary winding current 1 100mA
• Mounting PCB
• IP rating IP00
• Conform to the norm PN-EN 61558-1:2000,  PN-EN 61558-2-1:2000,  PN-EN 61558-2-6:2000
• Thermal class Ta60B
• Secondary winding terminals 07.сен
• Primary winding terminals 01.май
• Weight 70g
• A dimension 28mm
• A1 dimension 20mm
• A2 dimension 20mm
• B dimension 33mm
• C dimension 22mm
• Electrical insulation strength 4kV/60s
• Additional information
• Gross weight: 73.17 g
• Manufacturer part number: TEZ1.5/D230/15V

Parametri

15VAC
1
100mA
1.5VA

Papildu dokumentācija
