Apraksts

• Manufacturer SCI
• Type of switch ROCKER
• Contacts configuration SPDT
• Number of positions 2
• Switching method(the position in bracket indicates momentary position.) ON-ON
• AC contacts rating @R(at resistive load) 10A / 250V AC
• Key button colour black
• Illumination none
• Max. contact resistance: 50mΩ
• Body colour black
• Body material polyamide
• Flammability rating UL94V-2
• Operating temperature -20...85°C
• Leads 6,3x0,8mm connectors
• Panel thickness max. 3mm
• Electrical life 6000 cycles
• Mounting hole diameter 30.4x11.2mm
• Button marking blank
• Shape rectangular
• Manufacturer series R13-91-AC
• Stable positions number 2

Parametri

SPDT
10A/250VAC
ON-ON
2
IP00
2
Taustiņslēdzis
Ar fiksāciju
1
Bez apgaismojuma

Papildu dokumentācija
