Apraksts

• Manufacturer SCI
• Type of switch ROCKER
• Contacts configuration DPDT
• Number of positions 2
• Switching method
• (item in brackets is instantaneous) ON-ON
• AC contacts rating @R
• (at resistive load) 6A / 250V AC
• Key button colour black
• Illumination none
• Max. contact resistance: 50mΩ
• Body colour black
• Operating temperature -20...85°C
• Leads for soldering
• Panel thickness max. 6mm
• Electrical life 6000 cycles
• Mounting hole diameter Ø18.2mm
• Button marking I-O
• Shape rectangular
• Manufacturer series R13-136-AC
• Stable positions number 2
• Additional information
• Gross weight: 7.45 g
• Manufacturer part number: R13-136B-05-BB-2D

Parametri

DPDT
6A/250VAC
ON-ON
2
IP00
2
Taustiņslēdzis
Ar fiksāciju
2
Bez apgaismojuma

Papildu dokumentācija
