Apraksts

• Manufacturer SCI
• Type of switch ROCKER
• Contacts configuration DPDT
• Number of positions 2
• Switching method
• (item in brackets is instantaneous) ON-ON
• AC contacts rating @R
• (at resistive load) 3A / 250V AC
• Key button colour black
• Illumination none
• Max. contact resistance: 50mΩ
• Body colour black
• Leads for soldering
• Mounting hole diameter Ø12.2mm
• Button marking I-O
• Shape rectangular
• Manufacturer series R13-213-AC
• Body dimensions 20.3x14.4x13.5mm
• Stable positions number 2 Additional information
• Gross weight: 4.25 g
• Manufacturer part number: R13-213B-03-BBNN

Parametri

DPDT
3A/250VAC
ON-ON
2
IP00
2
Taustiņslēdzis
Ar fiksāciju
2
Bez apgaismojuma

Papildu dokumentācija
