Apraksts

• Specification
• Switch type ROCKER
• Contacts configuration SPST
• AC contacts rating
• (at resistance load) 6 A / 250 VAC
• DC contacts rating
• (at resistance load) 20 A / 12 VDC
• Switching method ON-OFF
• Actuator colour blue
• Max. contact resistance: 50mΩ;
• Body colour black
• Flammability rating UL94V-2
• Illumination neon lamp 230V
• Panel thickness max 3mm
• Electrical life 6000cycles
• Operating temperature -20...85°C
• Button marking --O
• Body material polyamide

Parametri

SPST
6A/250VAC
20A/12VDC
OFF-ON
2
IP00
2
Taustiņslēdzis
Ar fiksāciju
1
230VAC
