Apraksts

• Manufacturer C&K
• Type of switch microswitch TACT
• Contacts configuration SPST
• Number of positions 2
• DC contacts rating @R
• (at resistive load) 0.05A / 12V DC
• Mounting THT
• Illumination none
• Operating Force 1.8N
• Button height
• (measured from PCB) 12mm
• Switching method
• (item in brackets is instantaneous) OFF-(ON)
• Button shape round
• Operating temperature -20...70°C
• Leads for soldering
• Max. contact resistance: 100mΩ
• Min. insulation resistance 100MΩ
• Manufacturer series PTS125
• Kind of package bag
• Quantity in package 500pcs.
• Body dimensions 12x12mm
• Stable positions number 1 Additional information
• Gross weight: 15 g

Parametri

THT
SPST-NO
0.05A/12VDC
12x12x4mm
1.8N
8mm
Horizontāli

Papildu dokumentācija
