Apraksts

• Manufacturer: Texas Instruments
• Product Category: Operational Amplifiers - Op Amps
• RoHS: Details
• Mounting Style: SMD/SMT
• Package/Case: SOIC-14
• Number of Channels: 4 Channel
• Supply Voltage - Max: 30 V
• GBP - Gain Bandwidth Product: 1 MHz
• Output Current per Channel: 10 mA
• SR - Slew Rate: 3.5 V/us
• Vos - Input Offset Voltage: 15 mV
• Supply Voltage - Min: 7 V
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 85 C
• Ib - Input Bias Current: 400 pA
• Operating Supply Current: 200 uA
• Shutdown: No Shutdown
• CMRR - Common Mode Rejection Ratio: 86 dB
• en - Input Voltage Noise Density: 42 nV/sqrt Hz
• Series: TL064
• Packaging: Tube
• Amplifier Type: Low Power Amplifier
• Brand: Texas Instruments
• Dual Supply Voltage: +/- 5 V, +/- 9 V, +/- 12 V, +/- 15 V
• Height: 1.58 mm
• Input Type: Rail-to-Rail
• Length: 8.65 mm
• Maximum Dual Supply Voltage: 18 V
• Minimum Dual Supply Voltage: 3.5 V
• Operating Supply Voltage: 15 V
• Product: Operational Amplifiers
• Product Type: Op Amps - Operational Amplifiers
• 50
• Subcategory: Amplifier ICs
• Supply Type: Single, Dual
• Technology: BiFET
• Vcm - Common Mode Voltage: Negative Rail + 4 V to Positive Rail - 4 V
• Voltage Gain dB: 75.56 dB
• Width: 3.91 mm
• Unit Weight: 129,400 mg
