Apraksts

• Manufacturer: NXP
• Product Category: Audio Amplifiers
• RoHS: Details
• Product: Audio Amplifiers
• Class: Class-D
• Output Power: 210 W
• Mounting Style: SMD/SMT
• Type: 1-Channel Mono or 2-Channel Stereo
• Package/Case: HSOP-24
• Audio - Load Impedance: 8 Ohms
• THD plus Noise: 0.02 %
• Supply Voltage - Max: 30 V
• Supply Voltage - Min: 12.5 V
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 85 C
• Packaging: Cut Tape
• Packaging: MouseReel
• Packaging: Reel
• Description/Function: Speaker
• Height: 3.5 mm
• Input Type: Differential
• Length: 16 mm
• Output Current: 8000 mA
• Supply Type: Dual
• Width: 11.1 mm
• Brand: NXP Semiconductors
• Gain: 36 dB
• Number of Channels: 2 Channel
• CMRR - Common Mode Rejection Ratio: 75 dB
• Dual Supply Voltage: +/- 27 V
• Maximum Dual Supply Voltage: +/- 30 V
• Minimum Dual Supply Voltage: +/- 12.5 V
• Operating Supply Current: 65 mA
• Operating Supply Voltage: + / - 12.5 V to + / - 30 V
• Output Signal Type: Differential, Single
• Product Type: Audio Amplifiers
• Factory Pack Quantity: 500
• Subcategory: Audio ICs
• Part # Aliases: TDA8920BTH-T
• Unit Weight: 2,042 g
