TDA7575B Mikroshēma Audio Amplifiers 2 x 75W Multifunct Dual-Bridge Pwr Amp, FLEXIWATT-27
TDA7575B Mikroshēma Audio Amplifiers 2 x 75W Multifunct Dual-Bridge Pwr Amp, FLEXIWATT-27

* Produktu fotogrāfijas ir tikai noskatīšanai un var dažreiz atšķirties no priekšmeta reāla izskata. Bet galvenās īpašības ir vienādas.

TDA7575B Mikroshēma Audio Amplifiers 2 x 75W Multifunct Dual-Bridge Pwr Amp, FLEXIWATT-27

Cena: 8.54 €
00019866
TDA7575B
2
  • Apraksts

    • Manufacturer: STMicroelectronics
    • Product Category: Audio Amplifiers
    • RoHS:
    • Class: Class-AB
    • Output Power: 75 W, 150 W
    • THD plus Noise: 0.15 %
    • Package/Case: Flexiwatt-27
    • Audio - Load Impedance: 2 Ohms
    • Supply Voltage - Min: 8 V
    • Supply Voltage - Max: 18 V
    • Minimum Operating Temperature: - 55 C
    • Maximum Operating Temperature: + 150 C
    • Mounting Style: Through Hole
    • Series: TDA7575B
    • Qualification: AEC-Q100
    • Packaging: Tube
    • Brand: STMicroelectronics
    • CMRR - Common Mode Rejection Ratio: 56 dB
    • Description/Function: Speaker
    • Gain: 26 dB
    • Height: 15.7 mm
    • Input Type: Differential
    • Length: 29.23 mm
    • Number of Channels: 2 Channel
    • Operating Supply Voltage: 18 V
    • Output Current: 8 A
    • Output Signal Type: Differential
    • Pd - Power Dissipation: 86 W
    • Product: Audio Amplifiers
    • Product Type: Audio Amplifiers
    • PSRR - Power Supply Rejection Ratio: 60 dB
