Apraksts

• Manufacturer XINYA
• Type of connector pluggable terminal block
• Contacts pitch 5.08mm
• Number of ways 5
• Spatial orientation  straight
• Connector socket
• Kind of connector male
• Mechanical mounting on PCBs
• Electrical mounting THT
• Colour green
• Rated voltage  300V
• Type of pin configuration 1x5
• Current rating 15A
• Body material polyamide 66
• Locking system friction lock
• Flammability rating UL94V-0
• Conform to the norm UL
• Contact plating tinned
• Operating temperature -40...105°C
• Contact material brass
• Number of pins 5
• Connector variant without side walls
• Height 12mm
• Connectors features assembling possibility
• Additional information
• Gross weight: 1.6 g
• Manufacturer part number: XY2500V-C(5.08)-5PIN

Parametri

5
Spraudnis
Taisns
5.08mm
Terminal blocks PCB

Papildu dokumentācija
