Apraksts

• Manufacturer NINIGI
• Connector type pluggable terminal block
• Contacts pitch 5.08mm
• Number of ways 4
• Spatial orientation angled 90°
• Connector socket
• Connector type male
• Mechanical mounting on PCBs
• Electrical mounting THT
• Type of pin configuration 1x4
• Colour green
• Locking system friction lock
• Rated voltage 300V
• Rated current 15A
• Body material polyamide
• Flammability rating UL94V-0
• Contact plating tinned
• Operating temperature -40...105°C
• Contact material brass
• Number of pins 4
• Connector variant without side walls
• Height 8mm
• Depth 12.3mm
• Connectors features assembling possibility
• Length 20.32mm
• Soldering temperature 250°C / 5 s

Parametri

4
Spraudnis
5.08mm
Leņķisks 90°
Terminal blocks PCB
