Apraksts

• Manufacturer DEGSON ELECTRONICS
• Type of connector pluggable terminal block
• Contacts pitch 3.81mm
• Number of ways 10
• Spatial orientation  straight
• Connector plug
• Kind of connector female
• Mechanical mounting for cable
• Electrical mounting cage clamp,  screw terminal
• Colour green
• Rated voltage  250V
• Current rating 7A
• Type of pin configuration 1x10
• Body material PA66
• Locking system friction lock
• Flammability rating UL94V-0
• Conform to the norm CE,  UL,  VDE
• Operating temperature -40...105°C
• Contact material phosphor bronze
• Number of terminals 10
• Wire size 28AWG...16AWG
• Wire cross section 0.5...1.5mm2
• Additional information
• Gross weight: 7.3 g
• Manufacturer part number: 15EDGK-3.81-10P-14-00A(H)

Parametri

10
Ligzda
Taisns
3.81mm
Terminal blocks vadam

Papildu dokumentācija
