Apraksts

• Manufacturer CANAL ELECTRONIC
• Type of switch slide
• Number of positions 2
• Contacts configuration  DPDT
• DC contacts rating @R  0.3A / 30V DC
• Switching method  ON-ON
• Mounting THT
• Leads for PCB,  straight
• Operating temperature -20...60°C
• Body dimensions 8.5x6.8x4.7mm
• Manufacturer series SS008
• Max. contact resistance: 50mΩ
• Knob height 4mm
• Electrical life 10000 cycles
• Terminal pitch 2mm
• Contact material copper alloy
• Row pitch 2.5mm
• Actuator material thermoplastic material PPA
• Body material steel
• Terminals material copper alloy
• Body plating nickel
• Stable positions number 2
• Additional information
• Gross weight: 0.718 g
• Manufacturer part number: SS008B-02P-22

Parametri

DPDT
0.3A/30VDC
2
ON-ON
2

Papildu dokumentācija
