• Specification
• Generator type function
• Waveform frequency range accuracy: 10 ppm for 1 year; ±1 mHz below 0,2 Hz, maximal resolution: 1m or 6 digits, range: 1mHz...10MHz (other waveforms), range: 1mHz...10MHz (rectangular waveform), range: 1mHz...10MHz (sin waveform), range: 1mHz...1MHz (triangle waveform)
• Display LCD 4x20 characters
• Output parameters amplitude without load: 5mVpp-20Vpp, amplitude at 50Ω; load: 2,5mVpp-10Vpp, amplitude accuracy: ±3% ±1mV at 1kHz 50Ω;/600Ω;, impedance: 50Ω; or 600Ω;, amplitude flatness: ±2dB to 500Hz; ±1dB to 10MHz
• Rectangular waveform parameters rise/fall time: <22ns, aberrations: 5% + 2 mV
• Sweep mode period: 50m...999s (resolution 3 digits), mode: linear or logarithmic; single or continous
• Harmonic distortion level < -35dBc (<10MHz), typically < -40dBc, < -45dBc (<300kHz), < 0,3% THD (<20kHz), typically 0,1%
• Triangle waveform parameters linearity: <0,5% to 100 kHz
• Pulse signal amplitude at 50Ω; load: 2,5mVpp-10Vpp (with respect to DC offset baseline)
• External amplitude modulation carrier frequency: 1 mHz...10 MHz, carrier waveforms: all, modulation source: VCA IN socket
• Power supply 230VAC ±10% 50/60Hz
• Weight 2kg
• Dimensions 260 x 88 x 235mm
• Additional information
• Gross weight:2.64 kg
