Apraksts

• Manufacturer OMRON Electronic Components
• Type of relay electromagnetic
• Contacts configuration SPST-NO
• Contacts configuration
• Rated coil voltage 5V DC
• Contact current max. 15A
• AC contacts rating @R(at resistive load) 10A / 2500V AC
• at resistive load
• DC contacts rating @R(at resistive load) 10A / 30V DC
• at resistive load
• Manufacturer series G5CA
• Switched voltage max. 125V DC, max. 250V AC
• Relay variant miniature
• Mounting PCB
• Coil resistance 125Ω
• Operate time 10ms
• Body dimensions 22x16x11mm
• Release time 10ms
• Coil power consumption 200mW
• Operating temperature -25...70°C
• Contact resistance 30mΩ
• Terminal pitch 10,16mm
• Coil current 40mA
• Masa bruto7.84 g

Parametri

OMRON
DC5V
SPST-NO
10A/250VAC
10A/30VDC
uz pārslēgšanu
monostabilais
1

Papildu dokumentācija
