Apraksts

• Manufacturer PANASONIC
• Type of relay electromagnetic
• Contacts configuration  SPDT
• Rated coil voltage 5V DC
• AC contacts rating @R  10A / 250V AC
• (at resistive load)
• DC contacts rating @R  5A / 30V DC
• (at resistive load)
• Contact current max. 10A
• Switched voltage max. 100V DC,  max. 250V AC
• Relay variant miniature
• Mounting PCB
• Coil resistance 69.4Ω
• Coil voltage min. 3.5V DC
• Body dimensions 22x16x16mm
• Coil power consumption 360mW
• Mechanical durability 10000000 cycles
• Operating temperature -40...105°C
• Relay series JS
• Contact material AgSnO2
• Coil current 72mA
• Additional information
• Gross weight: 10.19 g
• Manufacturer part number: JS15FT

Parametri

PANASONIC
DC5V
SPDT
10A/250VAC
5A/30VDC
uz pārslēgšanu
monostabilais
1
1
