Apraksts

• Manufacturer OMRON
• Type of relay electromagnetic
• Contacts configuration SPDT
• Rated coil voltage 24V DC
• AC contacts rating @R
• (at resistance load) 8A / 250V AC
• DC contacts rating @R
• (at resistance load) 5A / 30V DC
• Contact current max. 8A
• Switched voltage max. 30V DC, max. 250V AC
• Relay variant miniature
• Mounting PCB
• Coil resistance 2.62kΩ
• Operate time 15ms
• Body dimensions 28.5x10x15mm
• Release time 5ms
• Coil power consumption 220mW
• Operating temperature -40...85°C
• Relay series G6RN
• Terminal pitch 3.2mm
• Coil current 9.2mA

Parametri

OMRON
DC24V
SPDT
8A/250VAC
5A/30VDC
uz pārslēgšanu
monostabilais
1

Papildu dokumentācija
