Apraksts

• Manufacturer RELPOL
• Type of relay electromagnetic
• Contacts configuration SPDT
• Rated coil voltage 12V DC
• Contact current max. 8A
• AC contacts rating @R 8A / 250V AC
• DC contacts rating @R 8A / 24V DC
• Manufacturer series RM96-1P
• Switched voltage max. 120V DC, max. 440V AC
• Relay variant miniature
• Mounting PCB
• Coil resistance 660Ω
• Coil voltage min. 8,4V DC
• Coil voltage max. 29,5V DC
• Operate time 10ms
• Body dimensions 30x10x16,2mm
• Release time 5ms
• Coil power consumption 300mW
• IP rating IP67
• Mechanical durability 20000000 cykli
• Contact resistance 100mΩ
• Contact material AgSnO2
• Terminal pitch 3,2mm
• Height 16,2mm
• OEM number 852843
• Number of pins 5
• Operating temperature -40...80°C
• Masa bruto10.92 g

Parametri

12VDC
SPDT
uz pārslēgšanu
monostabilais
1
1
RELPOL
8A/240VAC
8A/24VDC

Papildu dokumentācija
