Apraksts

• Manufacturer LOVATO ELECTRIC
• Type of relay electromagnetic
• Contacts configuration SPDT
• Rated coil voltage 110V DC
• AC contacts rating @R
• (at resistive load) 16A / 250V AC
• DC contacts rating @R
• (at resistive load) 12A / 30V DC
• Contact current max. 16A
• Switched voltage max. 220V DC, max. 250V AC
• Relay variant miniature
• Mounting socket
• Coil power consumption 400mW
• Operating temperature -40...85°C
• Weight 40g
• Relay series HR50
• Contact resistance 100mΩ
• Contact material AgNi Additional information
• Gross weight: 14.67 g
• Manufacturer part number: HR501CD110

Parametri

LOVATO ELECTRIC
110VDC
SPDT
16A/250VAC
12A/30VDC
uz pārslēgšanu
monostabilais
1

Papildu dokumentācija
