Apraksts

• Manufacturer: ON Semiconductor
• Product Category: Triac & SCR Output Optocouplers
• RoHS: Details
• Package/Case: PDIP-6
• Zero-Crossing Circuit: With Zero-Crossing Circuit
• Output Type: PhotoTriac
• Number of Channels: 1 Channel
• Isolation Voltage: 5250 Vrms
• If - Forward Current: 60 mA
• Vf - Forward Voltage: 1.25 V
• Pd - Power Dissipation: 250 mW
• Off-state Output Voltage - VDRM: 250 V
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 85 C
• Series: MOC3033M
• Packaging: Tube
• Height: 3.53 mm
• Length: 8.89 mm
• Width: 6.6 mm
• Brand: ON Semiconductor / Fairchild
• Mounting Style: Through Hole
• Maximum Trigger Current: 5 mA
• Product Type: Triac & SCR Output Optocouplers
• Factory Pack Quantity: 1000
• Subcategory: Optocouplers
• Zero-Crossing Voltage: 20 V
• Part # Aliases: MOC3033M_NL
• Unit Weight: 855 mg
