Apraksts

• Manufacturer: STMicroelectronics
• Product Category: MOSFET
• RoHS: Details
• Technology: Si
• Mounting Style: SMD/SMT
• Package/Case: SOIC-8
• Transistor Polarity: N-Channel
• Number of Channels: 1 Channel
• Vds - Drain-Source Breakdown Voltage: 20 V
• Id - Continuous Drain Current: 6 A
• Rds On - Drain-Source Resistance: 30 mOhms
• Vgs - Gate-Source Voltage: - 12 V, + 12 V
• Vgs th - Gate-Source Threshold Voltage: 600 mV
• Qg - Gate Charge: 11.5 nC
• Minimum Operating Temperature: - 55 C
• Maximum Operating Temperature: + 150 C
• Pd - Power Dissipation: 2.5 W
• Channel Mode: Enhancement
• Tradename: STripFET
• Series: STS6NF20V
• Packaging: Reel
• Packaging: Cut Tape
• Packaging: MouseReel
• Brand: STMicroelectronics
• Configuration: Single
• Fall Time: 10 ns
• Height: 1.65 mm
• Length: 5 mm
• Product Type: MOSFET
• Rise Time: 33 ns

Parametri

20V
8.7A
2.5W
0R022
SO8
