Apraksts

• Manufacturer: Analog Devices Inc.
• Product Category: Precision Amplifiers
• RoHS: Details
• Series: LT1125
• Number of Channels: 4 Channel
• GBP - Gain Bandwidth Product: 12.5 MHz
• SR - Slew Rate: 4.5 V/us
• CMRR - Common Mode Rejection Ratio: 126 dB
• Output Current per Channel: 22 mA
• Ib - Input Bias Current: 7 nA
• Vos - Input Offset Voltage: 30 uV
• en - Input Voltage Noise Density: 2.7 nV/sqrt Hz
• Supply Voltage - Max: 44 V
• Supply Voltage - Min: 8 V
• Operating Supply Current: 2.3 mA
• Minimum Operating Temperature: 0 C
• Maximum Operating Temperature: + 70 C
• Shutdown: No Shutdown
• Mounting Style: Through Hole
• Package/Case: PDIP-14
• Packaging: Tube
• Amplifier Type: High Speed Amplifier
• Brand: Analog Devices
• Gain V/V: 15 V/uV
• In - Input Noise Current Density: 0.3 pA/rtHz
• Ios - Input Offset Current: 7 nA
• Product: Precision Amplifiers
• Product Type: Precision Amplifiers
• PSRR - Power Supply Rejection Ratio: 124 dB
• 25
• Subcategory: Amplifier ICs
• Unit Weight: 3,348 g
