Apraksts

• Manufacturer: Texas Instruments
• Product Category: Analog Comparators
• RoHS: Details
• Mounting Style: SMD/SMT
• Package/Case: PDIP-14
• Number of Channels: 4 Channel
• Output Type: Rail-to-Rail
• Response Time: 1.3 us
• Comparator Type: Differential
• Supply Voltage - Min: 2 V
• Supply Voltage - Max: 30 V
• Operating Supply Current: 2 mA
• Output Current per Channel: 6 mA
• Vos - Input Offset Voltage: 7 mV
• Ib - Input Bias Current: 250 nA
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 125 C
• Series: LM2901
• Packaging: Tube
• Features: Standard comparator
• Height: 4.57 mm
• Length: 19.3 mm
• Product: Analog Comparators
• Supply Type: Single, Dual
• Technology: Bipolar
• Type: Differential Comparator
• Width: 6.35 mm
• Brand: Texas Instruments
• Shutdown: No Shutdown
• Dual Supply Voltage: +/- 3 V, +/- 5 V, +/- 9 V, +/- 12 V
• GBP - Gain Bandwidth Product: -
• Ios - Input Offset Current: 50 nA
• Maximum Dual Supply Voltage: +/- 15 V
• Minimum Dual Supply Voltage: 1 V
• Operating Supply Voltage: 2 V to 30 V
• Pd - Power Dissipation: 1050 mW
• Product Type: Analog Comparators
• Reference Voltage: Yes
• Subcategory: Amplifier ICs
• Voltage Gain dB: 100 dB
• Unit Weight: 1 g
