Apraksts

• Manufacturer: STMicroelectronics
• Product Category: Gate Drivers
• RoHS: Details
• Product: Half-Bridge Drivers
• Type: High-Side, Low-Side
• Mounting Style: Through Hole
• Package/Case: DIP-8
• Number of Drivers: 2 Driver
• Number of Outputs: 2 Output
• Supply Voltage - Min: - 300 mV
• Supply Voltage - Max: 17 V
• Rise Time: 50 ns
• Fall Time: 30 ns
• Minimum Operating Temperature: - 45 C
• Maximum Operating Temperature: + 125 C
• Series: L6385E
• Packaging: Tube
• Brand: STMicroelectronics
• Logic Type: CMOS, TTL
• Maximum Turn-Off Delay Time: 105 ns
• Maximum Turn-On Delay Time: 110 ns
• Off Time - Max: 105 ns
• Operating Supply Current: 250 uA
• Operating Supply Voltage: 15 V
• Output Voltage: 580 V
• Pd - Power Dissipation: 750 mW
• Product Type: Gate Drivers
