Apraksts

• Manufacturer KEMET
• Type of capacitor polypropylene
• Capacitance 68nF
• Terminal pitch 27.5mm
• Tolerance ±5%
• Body dimensions 32x13x22mm
• Climate class 55/105/56 IEC 60068-1
• Operating temperature -55...105°C
• Enclosure material self-extinguishing, UL94V-0
• Pulse resistance 2.3kV/μs
• Mounting THT
• Series R76
• Lead length 30mm
• Alias 76UR26804030J
• Capacitance - µF 0.068µF
• Max. operating voltage 700V AC, 2kV DC Additional information
• Gross weight: 10.55 g
• Manufacturer part number: R76UR26804030J

Parametri

68nF
2000VDC
KEMET
700VAC
±5%

Papildu dokumentācija
