Apraksts

• Manufacturer WIMA
• Type of capacitor polypropylene
• Capacitance 680nF
• Terminal pitch 37.5mm
• Tolerance ±10%
• Capacitor application high frequency circuits, impulse circuits
• Body dimensions 24x45.5x41.5mm
• Climate class 55/100/56
• Operating temperature -55...100°C
• Enclosure material self-extinguishing, UL94V-0
• Pulse resistance 900V/μs
• Mounting THT
• Capacitance - µF 0.68µF
• Max. operating voltage 2kV DC, 700V AC Capacitors features:
• low dielectric loss factor
• low ESR resistance value
• Additional information
• Gross weight: 49.6 g
• Manufacturer part number: MKP1U036807H00KSSD

Parametri

680nF
2000VDC
WIMA
700VAC
±10%

Papildu dokumentācija
