Apraksts

• Manufacturer KEMET
• Type of capacitor polypropylene
• Manufacturer series R76
• Capacitance 4.7nF
• Max. operating voltage 250V AC630V DC
• Body dimensions 10x4x9mm
• Mounting THT
• Tolerance ±5%
• Terminal pitch 7.5mm
• Pulse resistance 2.8kV/μs
• Lead length 4mm
• Conform to the norm AEC Q200
• Flammability rating UL94V-0
• Operating temperature -55...105°C
• Climate class
• 55/105/56
• IEC 60068-1
• Gross weight0.537 g

Parametri

4.7nF
630VDC
KEMET
±5%
250VAC

Papildu dokumentācija
