Apraksts

• Manufacturer WIMA
• Type of capacitor polypropylene
• Capacitance 47nF
• Terminal pitch 15mm
• Tolerance ±10%
• Capacitor application high frequency circuits, impulse circuits
• Body dimensions 5x11x18mm
• Climate class 55/100/56
• Operating temperature -55...100°C
• Enclosure material self-extinguishing, UL94V-0
• Pulse resistance 900V/μs
• Mounting THT
• Kind of package tape
• Max. operating voltage 250V AC, 400V DC Capacitors features:
• low dielectric loss factor
• low ESR resistance value
• Additional information
• Gross weight: 0.01 g

Parametri

47nF
400VDC
WIMA
250VAC
±10%

Papildu dokumentācija
