Apraksts

• Manufacturer WIMA
• Type of capacitor polypropylene
• Capacitance 470nF
• Terminal pitch 37.5mm
• Tolerance ±20%
• Capacitor application high frequency circuits,  impulse circuits
• Body dimensions 20x39.5x41.5mm
• Leads dimensions len. 6mm
• Climate class 55/100/56
• Operating temperature -55...100°C
• Enclosure material self-extinguishing, UL94V-0
• Pulse resistance 900V/μs
• Mounting THT
• Max. operating voltage 700V AC,  2kV DC
• Capacitors features
• low dielectric loss factor
• low ESR resistance value
• Additional information
• Gross weight: 34.9 g
• Manufacturer part number: MKP1U034707G00MSSD

Parametri

470nF
2000VDC
WIMA
700VAC
±20%

Papildu dokumentācija
