Apraksts

• Manufacturer KEMET
• Type of capacitor polypropylene
• Capacitance 22nF
• Terminal pitch 15mm
• Tolerance ±5%
• Body dimensions 18x5x11mm
• Climate class 55/105/56 IEC 60068-1
• Operating temperature -55...105°C
• Enclosure material self-extinguishing, UL94V-0
• Pulse resistance 2.5kV/μs
• Mounting THT
• Series R76
• Lead length 30mm
• Alias 76PI22204030J
• Max. operating voltage 400V AC,  630V DC
• Conform to the norm AEC-Q200
• Additional information
• Gross weight: 1.5 g
• Manufacturer part number: R76PI22204030J

Parametri

22nF
630VDC
400VAC
KEMET
±5%

Papildu dokumentācija
