Apraksts

• Manufacturer NINIGI
• Type of switch rotary
• Number of positions 4
• DC contacts rating @R  0.3A / 16V DC
• Poles number 1
• Indexed positions 30°
• Operating temperature -20...70°C
• Leads for PCB,  straight
• Contact material brass
• Switching method  BBM (non-shorting)
• Max. contact resistance: 50mΩ
• Body material steel
• Min. insulation resistance 100MΩ
• Mechanical durability 10000 cycles
• Shaft surface smooth
• Shaft diameter 6mm
• Shaft length 7mm
• Fastening thread M9x0,75
• Switching torque 2.9Ncm
• Stable positions number 4
• Additional information
• Gross weight: 7.15 g

Parametri

0.3A/16VDC
4
Galetes parslēdzejs
1
