Apraksts

• Manufacturer NINIGI
• Type of switch rotary
• Number of positions 10
• AC contacts rating @R
• (at resistive load) 0.3A / 125V AC
• Poles number 1
• Indexed positions 30°
• Operating temperature -20...70°C
• Leads for soldering
• Contact material brass
• Switching method
• (item in brackets is instantaneous) BBM (non-shorting)
• Max. contact resistance: 30mΩ
• Min. insulation resistance 100MΩ
• Mechanical durability 6000 cycles
• Shaft surface smooth
• Shaft diameter 6mm
• Shaft length 15mm
• Fastening thread 3/8"-32NEF
• Switching torque 4.9Ncm
• Stable positions number 10 Additional information
• Gross weight: 9.45 g

Parametri

10
Galetes parslēdzejs
1
0.3A/125VDC
