• Manufacturer: Vishay
• Product Category: Infrared Receivers
• RoHS: Details
• Mounting Style: Through Hole
• Carrier Frequency: 36 kHz
• Transmission Distance: 45 m
• Beam Angle: 45 deg
• Viewing Angle: 45 deg
• Minimum High Level Output Voltage: 100 mV
• Output Current: 5 mA
• Operating Supply Voltage: 2.5 V to 5.5 V
• Operating Supply Current: 350 uA
• Pd - Power Dissipation: 10 mW
• Minimum Operating Temperature: - 25 C
• Maximum Operating Temperature: + 85 C
• Package/Case: Side Looker
• Packaging: Tube
• Brand: Vishay Semiconductors
• Data Transmission Rate: 800 bits/s
• Height: 6.95 mm
• Length: 6 mm
• Product Type: IR Receivers
• Series: TSOP
