Apraksts

• Manufacturer BOURNS
• Type of encoder incremental
• Mounting THT
• Resolution 24imp/revol.
• Number of positions 24
• Output signal two phase A and B
• Mechanical durability 30000 cycles
• Operating voltage 5V DC
• Max. operating current 10mA
• Operating temperature -30...70°C
• Shaft surface D spring
• Shaft length 15mm
• Shaft diameter 6mm
• Cut depth 1.5mm
• Key stroke 0.5mm
• Encoders features with button
• Gross weight4.795 g
