Apraksts

• Manufacturer DELTRON
• Connector plug
• Type of connector DIN
• Kind of connector male
• Number of pins 6
• Connector pinout layout 240°
• Spatial orientation straight
• Information about relative position of each cable, terminals or PCB entry
• Mechanical mounting for cable
• Electrical mounting soldering
• Rated voltage 34V
• For products in the Cables and Wires category, a digit/digit number indicates:
• Rated volage U0/U
• where:
• U0 = cable nominal voltage between the conductor and the metal covering or earth
• U = cable nominal voltage between the phase conductors
• Current rating 2A
• Contact plating silver plated
• Max. contact resistance: 10mΩ
• Operating temperature -25...70°C
• Body coating nickel plated
• Enclosure material zinc alloy
• Gross weight22.83 g

Parametri

6
Spraudnis
Uz vadu
DIN
Vadam

Papildu dokumentācija
