Apraksts

• Manufacturer: Texas Instruments
• Product Category: Logic Gates
• RoHS: Details
• Product: Single-Function Gate
• Logic Function: NAND
• Logic Family: CD4000
• Number of Gates: 2 Gate
• Number of Input Lines: 2 Input
• Number of Output Lines: 1 Output
• High Level Output Current: - 85 mA
• Low Level Output Current: 0 mA
• Propagation Delay Time: 200 ns
• Supply Voltage - Max: 18 V
• Supply Voltage - Min: 3 V
• Minimum Operating Temperature: - 55 C
• Maximum Operating Temperature: + 125 C
• Mounting Style: Through Hole
• Package/Case: PDIP-8
• Packaging: Tube
• Brand: Texas Instruments
• Function: NAND
• Height: 4.57 mm
• Input Type: CMOS
• Length: 9.81 mm
• Logic Type: CMOS Dual 2-Input NAND Buffer/Driver
• Number of Bits: 2 bit
• Operating Supply Current: 60 uA
• Operating Supply Voltage: 10 V
• Operating Temperature Range: - 55 C to + 125 C
• Output Type: CMOS
• Product Type: Logic Gates
• Quiescent Current: 40 nA
• Series: CD40107B
• 50
• Subcategory: Logic ICs
• Width: 6.35 mm
• Unit Weight: 440,400 mg
