Apraksts

• Manufacturer AMASS
• Connector plug
• Type of connector DC supply
• Connector series XT90
• Kind of connector male
• Number of pins 4
• Mechanical mounting for cable
• Electrical mounting soldering
• Contact plating gold flash
• Colour yellow
• Current rating 40A
• Flammability rating UL94V-0
• Operating temperature -20...120°C
• Rated voltage  500V
• Spatial orientation  straight
• Contact material brass
• Mechanical durability 1000 cycles
• Wire size 10AWG
• Additional information
• Gross weight: 8.4 g
• Manufacturer part number: XT90I-M

Parametri

500V
2
Spraudnis
Taisns
40A
XT90

Papildu dokumentācija
