Apraksts

• Manufacturer BULGIN
• Connector type AC supply
• Standard IEC 60320
• Connector variant C20 (I)
• Connector socket
• Connector type male
• Body material polyamide
• Mechanical mounting for panel mounting, screw
• Rated current 16A
• Rated voltage 250V AC
• Leads 6.3x0.8mm connectors
• Mounting hole diameter 32.3 x 24.3mm
• Flammability rating UL94V-0
• Mounting holes pitch 42mm
• Operating temperature -40...70°C
• Mounting hole diameter 3.4mm

Parametri

Panelim
3
Spraudnis
C20
