Apraksts

• Manufacturer MEAN WELL
• Type of power supply unit switched-mode
• Kind of power supply modular
• Power 35W
• Output voltage 5V DC, 4.5...5.5V DC
• Body dimensions 99 x 82 x 30mm
• Output current 7A
• Weight 230g
• Number of outputs 1
• Mounting for building in
• Operating temperature -30...70°C
• Electrical connection terminal block
• Supply voltage 85...264V AC, 120...373V DC
• Protection overload, voltage growth, short-circuit
• Efficiency 82%
• Series LRS-35
• Kind of case 239A
• Dimensions see Power supply/converter features:
• no load power consumption <0,2W
• rated parameters obtained at full load
• Additional information
• Gross weight: 0.22 kg

Parametri

Skrūvju spailes
Modulis
5VDC
7A
35W

Papildu dokumentācija
