Apraksts

• Manufacturer MEAN WELL
• Type of power supply switched-mode
• Kind of power supply modular
• Power 102W
• Body dimensions 129x97x30mm
• Output current 8.5A
• Weight 340g
• Operating temperature -30...70°C
• Number of outputs 1
• Electrical connection terminal block
• Mounting for building in
• Protection overload, short-circuit, voltage growth
• Supply voltage 85...264V AC, 120...373V DC
• Efficiency 88%
• Series LRS-100
• Kind of case 238A
• Output voltage 10.2...13.8V DC, 12V DC

Parametri

Skrūvju spailes
Modulis
12VDC
8.5A
102W

Papildu dokumentācija
