Apraksts

• Specification
• Connector type SMB
• Connector plug
• Connector type female
• Connector variant straight
• Contact plating gold plated
• Rated voltage 335V
• Cable type B7805A, KX22, KX3, M17-113, M17-119, RG174, RG188(A), RG316
• Max. frequency 4GHz
• Insulator material teflon
• Test voltage 1kV
• Standing wave-ratio 1.41
• Attenuation coefficient 0.3dB
• Min. insulation resistance 1000MΩ;
• Max. contact resistance: 3mΩ;
• Wave impedance 50Ω;
• Mounting:
• crimped
• on cable

Parametri

Uz vadu
SMB
Spraudnis

Papildu dokumentācija
