Apraksts

• Specification
• Fan type DC
• Fan dimensions 80x80x25mm
• Bearing type ball bearing
• Fans efficiency 76.5m3/h
• Noise level 38dBA
• Supply voltage 12V DC
• Power consumption 1.8W
• Operating voltage 4.5...13.8V
• Rotational rate/speed 3600 (±10%)rpm
• Weight 89g
• Rated current 0.15A
• Current and power consumption tolerance ±15%
• Min. insulation resistance 500MΩ;
• Fan material thermoplastic
• Enclosure material thermoplastic
• Insulation class E
• Operating temperature -10...70°C
• Static pressure 5.84mm H2O
• Leads 2 leads
• Flammability rating UL94V-0
• Fan motor brushless DC motor
• Cable length 300mm
• Wire size 28AWG
• Additional functions Autorestart

Parametri

80x80x25mm
12VDC
uz ass
ritgultnis
76.5m3/st
38dBA
3600apgr.
1.8W

Papildu dokumentācija
