Apraksts

• Manufacturer SUNON
• Type of fan DC
• Kind of fan axial
• Operating voltage 4.5...13.8V
• Fan dimensions 50x50x15mm
• Power consumption 0.92W
• Current rating 0.072A
• Fan efficiency 28.73m3/h
• Noise level 33dBA
• Kind of Bearing Vapo
• Rotational rate/speed 6100rpm
• Current and power consumption tolerance ±15%
• Min. insulation resistance 10MΩ
• Impeller material thermoplastic
• Enclosure material thermoplastic
• Insulation class A
• Leads 2 leads
• Operating temperature -10...70°C
• Cable length 300mm
• Flammability rating UL94V-0
• Additional functions Autorestart
• Fan motor brushless DC
• Static pressure 5.84mm H2O
• Wire size 26AWG
• Weight 33g
• Supply voltage
• 12V DC
• Gross weight30.2 g

Parametri

50x50x15mm
12VDC
uz ass
MagLev
28.73m3/st
33dBA
6100apgr.
0.92W
