Apraksts

• Manufacturer: Texas Instruments
• Product Category: Flip-Flops
• RoHS: Details
• Number of Circuits: 8
• Logic Family: HCT
• Logic Type: D-Type Flip-Flop
• Polarity: Non-Inverting
• Input Type: TTL
• Output Type: CMOS
• Propagation Delay Time: 30 ns
• High Level Output Current: - 4 mA
• Low Level Output Current: 4 mA
• Supply Voltage - Min: 4.5 V
• Supply Voltage - Max: 5.5 V
• Minimum Operating Temperature: - 55 C
• Maximum Operating Temperature: + 125 C
• Mounting Style: Through Hole
• Package/Case: PDIP-20
• Packaging: Tube
• Brand: Texas Instruments
• Function: Octal with Reset
• Height: 4.57 mm
• Length: 24.33 mm
• Number of Channels: 8
• Number of Input Lines: 8
• Number of Output Lines: 8
• Operating Supply Voltage: 5 V
• Operating Temperature Range: - 55 C to + 125 C
• Product Type: Flip Flops
• Quiescent Current: 8 uA
• Reset Type: Master Reset
