Apraksts

• Manufacturer: Texas Instruments
• Product Category: Inverters
• RoHS: Details
• Number of Circuits: 6 Circuit
• Logic Family: HCT
• Logic Type: CMOS
• Supply Voltage - Max: 5.5 V
• Supply Voltage - Min: 4.5 V
• Minimum Operating Temperature: - 55 C
• Maximum Operating Temperature: + 125 C
• Mounting Style: SMD/SMT
• Package/Case: PDIP-14
• Packaging: Tube
• Brand: Texas Instruments
• Function: Inverter Schmitt Trigger
• High Level Output Current: - 5.2 mA
• Input Level: CMOS
• Input Type: Schmitt Trigger
• Low Level Output Current: 5.2 mA
• Number of Output Lines: 6 Output
• Operating Supply Voltage: 5 V
• Operating Temperature Range: - 55 C to + 125 C
• Output Level: TTL
• Output Type: CMOS
• Product Type: Inverters
• Propagation Delay Time: 48 ns
• Series: CD74HCT14
